Eaton Wheelock EL3RST-FW — white Eluxa outdoor LED strobe, NEMA type 3R, FIRE lettering.
Outdoor notification is a sealing problem as much as a signalling one, and Eluxa answers it in two enclosures. The 3R is the lighter and much shallower, shipping with a hinged pre-wire capable mounting plate that holds the device while it is terminated.
- Clear-lens candela settings 15, 30, 75, 110, 150 and 185
- Maximum current at 24 VDC regulated: 0.026, 0.038, 0.070, 0.097, 0.179 and 0.206 A
- On a full wave rectified supply: 0.034, 0.053, 0.098, 0.137, 0.235 and 0.308 A
- Operating voltage 16 to 33 VDC or FWR; flash rate 1 Hz with a 20 ms LED pulse
- NEMA type 3R and IP54 with the included mounting accessory; -40 to 150 °F at 95% RH
- 7.8 × 5.75 × 1.6 in. and 1.7 lb; LED behind a rugged Lexan lens
- Strobe only, no sounder; synchronises with Wheelock DSM modules
EL3RST-FR is the same strobe in red. EL4XST-FW is the NEMA 4X and IP66 equivalent, and that is not only a rating change: the 4X body is far deeper at 8 × 6.5 × 4.5 in., mounting to an EL4XBB back box rather than a plate. EL3RHS-FW adds a horn.
