Eaton Wheelock EL3RSPST-FW is an Eluxa outdoor NEMA 3R speaker strobe in white with FIRE lettering and a clear lens, supplied with the 3R mounting plate. Eluxa weatherproof models are for indoor or outdoor use and wall or ceiling mounting, and they install on the pre-wire capable EL3RBB mounting plate (3R) or the EL4XBB back box (4X).
The speaker runs at 25 or 70.7 Vrms across 400 to 4000 Hz, and the LED strobe has six candela settings: 15, 30, 75, 110, 150 and 185 cd, flashing at 1 Hz. All models synchronize with DSM modules or Wheelock power supplies, and the low current draw across the full candela range lets more appliances share each notification appliance circuit.
Specifications
| Strobe output |
15/30/75/110/150/185 cd, clear lens, 1 Hz |
| Strobe voltage |
16.0 to 33.0 VDC regulated, or FWR |
| Strobe current at 24 VDC |
0.026 A at 15 cd to 0.206 A at 185 cd |
| Speaker taps, 25 Vrms |
1/8 to 2 W, 76 to 88 dBA at 10 ft |
| Speaker taps, 70.7 Vrms |
1/8 to 8 W, 76 to 94 dBA at 10 ft |
| Wiring |
18 to 12 AWG, 2-wire |
| Operating temperature |
-40°F to 150°F (-40°C to 66°C), 95% RH |
| Dimensions |
7.8 x 5.75 x 1.6 in. (3R) |
| Weight |
1.7 lb (3R) |
| Lens |
LED in a Lexan lens |
Features
- Indoor and outdoor use, wall or ceiling mount
- Synchronizes with DSM modules or Wheelock power supplies
- Speaker dBA per UL 1480 / ULC S541 reverberant testing
- Letter plates such as ELLP-COR and ELLP-EVR are available for other wording
Related models
- EL3RSPST-FR: red version
- EL4XSPST-FW: NEMA 4X version with back box
- EL3RSPK-NW: speaker only, white
FAQ
Which candela settings does the EL3RSPST-FW have?
15, 30, 75, 110, 150 and 185 cd with a clear lens, flashing at 1 Hz.
Which speaker taps are available?
At 25 Vrms, 1/8 to 2 W (76 to 88 dBA at 10 ft); at 70.7 Vrms, 1/8 to 8 W (76 to 94 dBA at 10 ft).
How much current does the strobe draw?
At 24 VDC regulated it ranges from 0.026 A at 15 cd to 0.206 A at 185 cd; FWR values are higher, up to 0.308 A at 185 cd.
Can it sync with other strobes?
Yes. All models synchronize with DSM modules or Wheelock power supplies.
