Eaton EL3RMTST-FR — Wheelock Eluxa outdoor multi-tone horn strobe, NEMA 3R, clear lens, red housing with FIRE lettering.
A weatherproof LED appliance carrying an eight-tone audible and a six-setting strobe in one housing. It ships with its hinged, pre-wire capable 3R mounting plate, and Eaton states the NEMA 3R and IP54 ratings are reached only when that included mounting accessory is used.
- Six clear-lens settings: 15, 30, 75, 110, 150 and 185 cd, one flash per second, 20 ms pulse
- Eight tones — horn, bell, march time, Code 3 horn, Code 3 tone, slow whoop, siren, hi/lo
- Horn tone 88 dBA high and 83 dBA standard, reverberant at 10 ft per UL 464
- 16 to 33 VDC or VFWR; strobe draws 0.026 A at 15 cd and 0.206 A at 185 cd at 24 VDC
- 7.8 x 5.75 x 1.6 in., about 1.7 lb; rated to 150 °F at 95% RH; wall or ceiling
- UL 1971, UL 1638 and UL 464 certified, ULC-S525 and S526, FM and CSFM
EL3RMTST-FW is the same appliance in white and EL4XMTST-FR is the NEMA 4X and IP66 version. EL3RMT-NR is the multi-tone horn with no strobe, and EL3RMTSTA carries an amber lens on a different candela set.
Need this model in another color? See Eaton EL3RMTST-FW 3R Multitone Strobe with 3R Plate, White.
