E2S D1XCP1PSDDX1A1R — D1xCP1-PS dual-action explosion-proof manual pull station, red, cast aluminium.
E2S builds this part number from an ordering-code string: D1XCP1PS base station, D for the DPDT switch, D for the default two 3/4 in. NPT cable entries, X for no stopping plug, 1 for no duty label or equipment tag, A1 for the UL and SIL2 version, and R for red. It is a North American fire alarm device listed under UL 38, not an ATEX or IECEx zone-marked unit.
- UL and MEA listed; UL 38 manual signaling boxes for fire alarm systems; SIL2 compliant
- Class I Div. 1 Groups B, C and D; Class II Div. 1 Groups E, F and G; Class III Div. 1
- NEMA Type 4X and UL Marine listed; DPDT switch, 1 Amp @ 30 VDC, 10 Amp @ 120 VAC
- –40°C to +65°C (–40° to 150°F); 95% RH at 20°C
- 6 5/16 in. H × 3 1/4 in. W × 3 7/8 in. D; 4.8 lbs
- Dual action: a PUSH bar frees the PULL handle; key reset
Every character matters. Cable-entry letters A, B, C or E give M20 or 1/2 in. entries instead of the two 3/4 in. NPT of code D; N or S in place of X adds a stopping plug; duty-label digits 2, 3, 6 or 7 add tags this unit lacks.
