E2S D1XC1X05RDC024CN1A1R/C — D1xC1X05R explosion-proof combined alarm horn and 5 joule xenon strobe with omni-directional radial horn, 24 VDC, red enclosure, clear lens.
A full E2S configuration code: C = two 3/4 in. NPT adaptors, N = nickel plated, 1 = 316 stainless U bracket, A = UL/cUL/ULC, IECEx, ATEX version, 1 = standard, R = red, /C = clear lens. This 24 VDC clear-lens version is UL listed as a public-mode fire horn (UL 464) and private-mode strobe (UL 1638).
- Class I Div 1 ABCD and Zone 1 IIC, T4 to 85 °C ambient (NEC); Ex db IIC
- Horn: 110 dB(A) at 1 m maximum (tone 4), 105 dB(A) nominal; 64 tones, 4 stages
- Fire use: tone 12 (1000 Hz temporal) at full volume; minimum 83.4 dB(A) at 10 ft at 24 VDC (US)
- Strobe: 1 Hz, 1.5 Hz or double strike; UL 1638 rating 12 cd effective on axis at 1 Hz, 20 VDC
- 24 VDC: 508 mA nominal combined, 555 mA maximum at 20 VDC
- Aluminium, IP66/67, Type 4/4X/3R/13; 10.9 lb
Not the D1XC1X05RDC024BS1D1RR, a Class II (version D) unit with red lens. D1xC1X05F has the louder F horn; X10 models a 10 J strobe.
