E2S D1xB2XH1DC024MN0H1R/C — explosion proof 10 joule xenon strobe beacon, 24 V dc, red flameproof aluminium housing with a clear borosilicate lens.
Every character of the code is an ordering choice: D1xB2 the explosion proof warning light, XH1 the 10 joule xenon strobe, DC024 the 24 V dc supply, M two 3/4" NPT plus two M20 plus one 3/4" NPT entries, N brass plugs, 0 no lens guard, H1 the UL, cUL and ULC version, R red, /C clear.
- 86.37 cd effective intensity on axis at 1 Hz (60 fpm); 58.57 cd at 1.33 Hz and 51.65 cd at 1.5 Hz
- 635 mA nominal at 1 Hz, 765 mA maximum over 20 to 28 V dc
- UL 1971 Third Ed., UL 1638 Fifth Ed. and CAN/ULC-S526 Fourth Ed.
- Class I Div 1 Groups ABCD T5, Class II Div 1 Groups EFG, Ta to plus 80°C
- Marine grade LM6 aluminium, Type 4/4X/3R/13 and IP66/67
- Blocking diode for supervised circuits; units on one supply flash in step, no sync module
Read the flash rate before quoting the candela: only 1 Hz, 1.33 Hz and 1.5 Hz are public mode fire approved; the fourth setting is a double flash. The sibling to check is D1xB2XH2, the same enclosure with a 21 joule tube at 190.6 cd.
