DITEK DTK-DR24F Low Voltage DIN Rail Surge Protector, 24V, 1A
The DTK-DR24F is a DIN rail mounted surge protector for two 24 V low-voltage circuit pairs carrying up to 1 A. It uses a hybrid diode / gas discharge tube design with a removable protection module, and opens the circuit when the protection has been compromised. It is suitable for AC and DC circuits in industrial control, fire alarm and signaling applications.
Key Features
- Protects (2) 24 V circuit pairs
- Field-replaceable protection module (replacement: add "M" suffix to the part number)
- Hybrid SAD/TVS diode and GDT design
- Fails open circuit when compromised
- 35 mm DIN rail mounting
- Grounds through the DIN rail or the included grounding lug
- Suitable for AC and DC circuits
Specifications
| Service voltage |
24 VDC |
| MCOV |
33 V |
| Clamping voltage |
39 V |
| Surge current rating |
20,000 A |
| Max. continuous current |
1 A |
| Connection |
Screw terminals, 30-12 AWG |
| Housing |
ABS, UL94-V0, IP20 |
| Operating temperature |
-40 to 158 F (-40 to 70 C) |
| Dimensions |
4.0 x 0.48 x 2.92 in. (102 x 12 x 74 mm) |
| Weight |
3.2 oz (91 g) |
Compatible With
- 24 V signaling, 4-20 mA loop, RS-485 and low-voltage power circuits
- 35 mm DIN rail
