Det-Tronics 225130-005 is a certified calibration kit with hydrogen calibration gas for Det-Tronics CGS catalytic combustible gas sensors. The gas is 50% LFL hydrogen (2.0% by volume, NFPA basis) in an air balance.
The kit comes in a sturdy plastic carrying case with two 103 liter (3.6 cu ft) cylinders of Class 2.2 non-flammable, non-toxic compressed gas, a regulator and shutoff valve with gauge, 3 ft of tubing and a stainless steel CGS calibration cup. The regulator gives a fixed flow of 1 liter per minute, set for CGS sensors.
Specifications
| Gas |
Hydrogen, 50% LFL |
| Concentration |
2.0% by volume (NFPA) |
| Balance |
Air |
| Cylinders |
Two, 103 L (3.6 cu ft) each |
| Flow rate |
1 L/min fixed |
| Ship weight |
11.5 lb (5.23 kg) |
Features
- Regulator and shutoff valve with gauge
- 3 ft tube and stainless steel CGS calibration cup
- Plastic carrying case
- Spare 50% LFL hydrogen cylinder available as 226166-005
Related models
- 225130-001: same kit with 50% LFL methane
- 225130-009: empty kit with no calibration gas
Documents
FAQ
Which sensors is this kit for?
Det-Tronics CGS catalytic combustible gas sensors. The regulator is set to a fixed 1 liter per minute flow designed for CGS sensors.
What gas is in the kit?
Hydrogen at 50% LFL, which Det-Tronics lists as 2.0% by volume on the NFPA basis, balanced in air.
How do I get more gas?
The 226166-005 is the spare 50% LFL hydrogen cylinder for this kit.
Is there a methane version?
Yes. The 225130-001 kit uses 50% LFL methane, which Det-Tronics uses for FM and CSA verified calibration of the Model 505 CGS.
