BRK Electronics SA520B is a hardwired smoke alarm that works as a wireless bridge unit in the OneLink system. It has a photoelectric sensor, a replaceable battery backup and a silence feature.
OneLink alarms suit renovation and retrofit work where interconnection is needed, because alarms on different floors or in new and existing construction can be linked by radio as well as by hardwired interconnect.
Features
- Photoelectric sensing, single-button test/silence
- Two silence modes: low-battery chirp for up to eight hours, or temporary silence of a nuisance alarm
- Hardwired and RF interconnect; 915 MHz with 65,000 security codes and 3-channel frequency hopping
- Optipath 360 technology gives 360 degree access to the smoke sensor
- Perfect mount for easy alignment; alarm latch shows which unit started an alarm
- Spread spectrum horn tone, lower and varying in frequency for easier hearing by people with age-related hearing loss
Specifications
| Sensor |
Photoelectric |
| Interconnect |
Hardwired and wireless (RF) |
| Backup |
Replaceable battery |
| Mounting |
Ceiling or wall |
| Application |
Residential |
| Color |
White |
| Model |
SA520B |
| Operating Voltage |
120V AC with battery backup |
| Backup Batteries |
Two 1.5V AA alkaline |
| Sound Level |
85 dB at 10 feet |
| Operating Temperature |
40 °F to 100 °F (4 °C to 38 °C) |
| Relative Humidity |
10% to 95% |
| Dimensions |
5.0 in dia. x 2.0 in H |
| Includes |
Hardwire Adaptor Plug |
| Standards |
Certified to UL 217 |
| Warranty |
10 Years Limited |
Documents
FAQ
Does the SA520B work as a wireless bridge?
Yes. It is a hardwired 120 VAC alarm that also links by radio to other OneLink alarms, so hardwired and wireless alarms can sound together.
What backup power does it use?
Two 1.5 V AA alkaline batteries, which are replaceable.
How loud is it?
85 dB at 10 feet.
Where can it be mounted?
On a ceiling or wall, using the hardwire adaptor plug that is included.
