Autocall A606-9101 Foundation Series LCD Annunciator
The A606-9101 is a remote LCD annunciator for Autocall Foundation Series fire alarm control units. It repeats panel status on an LCD with dedicated status LEDs and a local tone-alert, and its acknowledge, silence and reset switches are enabled by a keyswitch. Up to four can be installed on an A008 (2008FS) panel and up to eight on A050 / A250 (2050FS / 2250FS) panels.
Key Features
- LCD display with five dedicated LEDs: general alarm, supervisory, trouble, alarm silenced and power on
- Keyswitch-controlled acknowledge, alarm silence, reset and scroll keys
- Local tone-alert (piezo)
- Communicates at 9600 baud; 24 VDC power supplied by separate wiring
- All connections power-limited and supervised
- For indoor use in a dry location
Specifications
| Operating voltage |
24 VDC nominal (16 to 30 VDC) |
| Current, backlight off |
40 mA standby / 48 mA alarm |
| Current, backlight on |
65 mA standby / 72 mA alarm |
| Dimensions |
5 3/8 in. H x 6 7/8 in. L x 1 3/8 in. D (13.65 x 17.46 x 3.49 cm) |
| Operating temperature |
32 to 120 F (0 to 49 C) |
| Storage temperature |
-4 to 158 F (-20 to 70 C) |
Compatible With
- A008-9101 (2008FS) FACU, firmware 1.07 or higher - up to 4 annunciators
- A050-9101 and A250-9101 (2050FS / 2250FS) FACUs, firmware 1.03 or higher - up to 8 annunciators
