WP MC VO NONADDR WALL RED
The A4906-9105 is a non-addressable weatherproof TrueAlert visible-only strobe for wall mounting, with a red housing and white lettering. It is built for indoor or outdoor use in extended temperature and humidity conditions and requires the matching weatherproof box, ordered separately. Red housings use a UV light-stable color.
Key Features
- Weatherproof multi-candela TrueAlert appliance for extended temperature and humidity
- NEMA 3R rated enclosure when installed with the matching weatherproof box (ordered separately)
- UL 1638 listed for outdoor use with the strobe rated 75 cd (WP75)
- UL 1971 listed for indoor use with selectable strobe intensity
- High-impact, flame-retardant thermoplastic housing with clear lens
- Wiring terminals accessible from the front of the housing
- Polarized input for supervised reverse-polarity NACs; SmartSync operation
- Red housing: indoor or outdoor applications, UV light-stable color
Specifications
| Rated voltage |
Regulated 24 VDC (16-33 VDC operating range) |
| Flash rate |
1 Hz, up to 24 synchronized strobes per NAC |
| Temperature range (UL 1638, 75 cd) |
-31 to 150 F (-35 to 66 C) |
| Temperature range (UL 1971) |
32 to 122 F (0 to 50 C) |
| Humidity (UL 1638) |
Up to 98% at 104 F (40 C) |
| Wiring connections |
Terminal blocks for 18 to 12 AWG, two wires per terminal |
| Max RMS current, UL 1971 (15 / 60 / 75 cd) |
77 / 192 / 231 mA |
| Max RMS current, UL 1638 75 cd |
189 mA (32 to 150 F); 273 mA (-31 to 32 F) |
Compatible With
- SmartSync notification appliance circuits
- Matching weatherproof mounting boxes (see datasheet)
