Autocall A4098-5601 Foundation Series Photoelectric Smoke Detector
The A4098-5601 is a conventional photoelectric smoke detector head for two-wire or four-wire initiating device circuits. An onboard microprocessor evaluates the light-scattering chamber and applies sensitivity drift compensation to reduce nuisance alarms. It installs on a separate base and is intended for indoor use.
Key Features
- Photoelectric light-scattering smoke detection with onboard microprocessor
- Sensitivity drift compensation for dust, dirt and component aging
- Dirty-detector status indicated through the status LED
- Magnetic test for status checks
- UL listed (the ULC-listed version is A4098-5603)
Specifications
| Operating voltage, two-wire |
10.5 to 33 VDC |
| Rated voltage, four-wire |
15 to 32 VDC |
| Standby current |
<70 uA |
| Max alarm current |
64 mA at 30 V, 33 mA at 20 V, 14.5 mA at 12 V |
| Air velocity range |
0-2000 FPM |
| Humidity |
10-95% RH, non-condensing |
| Ambient operating temperature |
32 to 100.4 F (0 to 38 C) |
| Height |
42 mm (1 5/8 in.); 53 mm (2 1/8 in.) with base |
| Material |
Flame retardant ABS or PC-ABS |
Compatible With
- Bases A4098-5207, A4098-5261, A4098-5680 and A4098-5682
- Conventional two-wire or four-wire initiating device circuits
