Apollo ORB-HT-11018-APO — Orbis conventional heat detector head, EN 54-5 Class CS (static, fixed temperature), flashing LED version.
A thermistor samples air temperature every two seconds and this head alarms at a fixed threshold with no rate-of-rise element: the Apollo choice where maximum ambient exceeds 65 °C and sudden heat rises are normal. The red LED flashes every four seconds in normal operation.
- Class CS: typical application 55 °C, maximum 80 °C; static response 84–100 °C, typical 90 °C
- Supply 8.5–33 VDC, two-wire, polarity sensitive; alarm load 600 Ω
- Operating temperature -40 to +70 °C; 0–98% RH non-condensing; IP44
- 97 mm diameter × 36 mm high; 70 g; white flame-retardant polycarbonate
- Declared to EN 54-5:2017+A1:2018; Apollo lists CPR, LPCB, BOSEC and CSIRO approvals, no UL certification
Mounts on an Orbis base ordered separately, such as the ORB-MB-00001-APO TimeSaver base. ORB-HT-11006-APO is the same head without the flashing LED; ORB-HT-11017-APO (CR) adds rate-of-rise at the same temperatures, and the A1R, A2S, BR and BS heads alarm lower.
