Ansul 443476 — CleanGuard+ CA07 hand portable clean agent fire extinguisher, 7.5 lb, rated 5-B:C.
ABC dry chemical puts the fire out but coats everything it reaches in a mildly corrosive powder, which is why it is the wrong appliance over a server rack or a fire alarm panel — cleanup routinely costs more than the fire did. CleanGuard+ discharges FK-5-1-12, a colorless, electrically non-conductive agent that evaporates and leaves no residue, so it can be used on energized electronics. The CA07 is the 7.5 lb size, a usual pick for telecom closets and equipment rooms.
- Model CA07, FK-5-1-12 clean agent, 7.5 lb (3.4 kg)
- UL/ULC rating 5-B:C
- Charged weight 12.12 lb (5.5 kg)
- 16 3/4" H × 8 1/2" W × 4 7/16" dia. (425 × 216 × 113 mm)
- Range 8 to 10 ft (2.4 to 3.1 m); discharge time approx. 8.2 s
- Standard bracket part no. 429146
Rated B:C only — if the hazard needs a Class A rating, step up to the CA13 (443477), rated 1-A:10-B:C. A vehicle bracket is a separate order, and this is the CA07, not the CA07VB.
Documents
FAQ
Is the agent safe on electronic equipment?
Yes. FK-5-1-12 is electrically non-conductive and residue-free, and does not cause thermal shock damage to delicate electronic equipment.
What is the rating of the CA07?
The CA07 (443476) is UL and ULC rated 5-B:C, with 7.5 lb (3.4 kg) of agent and an effective range of 8 to 10 ft.
Which size has a Class A rating?
The CA13 (443477) is rated 1-A:10-B:C and the CA25 (443478) is rated 2-A:10-B:C. The CA07 has no Class A rating.
Is it rechargeable, and what temperatures can it handle?
Yes, it is rechargeable. The operating temperature range is -40 °F to 120 °F (-40 °C to 49 °C).
