AD ASY FILL 50 VLV
Amerex P/N 06160 is a recharge (fill/pressurizing) adapter with a Hansen quick-connect fitting for Amerex 50 lb. stored-pressure wheeled extinguishers. It threads onto the 3/4"-11-1/2 NH discharge connection so the unit can be pressurized with nitrogen after recharge. Amerex also specifies it, together with plug P/N 06157, for hydrostatic testing of 1/2 in. hose assemblies on wheeled units.
Key Features
- Fill (recharge) adapter with Hansen quick connect
- Thread: 3/4"-11-1/2 NH
- For Amerex 50 lb. stored-pressure wheeled dry chemical extinguishers
- Attaches to the discharge port to pressurize the extinguisher with dry nitrogen (Amerex manual 05612)
- Used with plug P/N 06157 to hydro-test 1/2 in. hose assemblies on wheeled dry chemical, foam, Halon, Halotron and SF 1230 units
- Replacement adapter gasket: Amerex P/N 06056-P
Specifications
| Amerex part number |
06160 |
| Connection |
Hansen quick connect |
| Thread |
3/4"-11-1/2 NH |
| Replacement gasket |
06056-P |
Compatible With
- Amerex 50 lb. stored-pressure wheeled extinguishers
- Amerex 06157 hydro-test hose plug
